Communication POE Ethernet Switch , Network Fiber Converter Full Half Duplex

Name: Communication POE Ethernet Switch Network Fiber Converter Full Half Duplex
Brand: Sinohone
Price: 38.00 USD

Wholesale Communication POE Ethernet Switch , Network Fiber Converter Full Half Duplex from china suppliers

Certification : ROHS / UL /CE / CPR

Brand Name : Sinohone

Model Number : HY-648PI, Customized, LC, SC, FC, ST Adapters

Place of Origin : Sichuan, China

Supply Ability : 50000 Pieces per Month

Packaging Details : Standard packed in separate box and foam inside

MOQ : 1 Pieces

Price : $38.00~48.00 per piece

Products Status : Stock

Ports : ≤ 8

Transmission Rate : 10/100/1000Mbps

Function : LACP, POE, QoS, SNMP, Stackable, VLAN Support

Communication Mode : Full-Duplex & Half-Duplex

Switch Capacity : 53G

Key words : Industrial Switch

Application : Telecom/network

Exchange capacity : 53G

Type : Sliding Fixed

Operating temperature : -40°C to + 70°C

Product name : Fiber Optic Network Switch

Contact Now

Communication Industry 2/4/6/8/12/16/24 ports POE network switch 2019 New Arrival

HY-648 is our industrial grade switch, which can be powered by POE and can be used as a PTN remote device.

The product provides high-speed Ethernet service access and supports Ethernet standard protocols.

It simplifies the complex protocol overhead of PTN and provides the OAM capability of the service layer, which makes the design and implementation of the access network more general.

It has the ability to connect with PTN, simplify the operation interface, make the network maintenance means effective and unified, and help to achieve efficient network management.

Product Description

Characteristics:

Item	HY-648PI
Number of interfaces	Gigabit SFP ports (or specify other optical port forms):4 Gigabit ports (POE power supply):8
Exchange capacity	53G
Mpps	17.85Mpps
POE power supply	Support
PTN ring network	Support PTN industrial ring network technology, using ERPS protocol, STP protocol
VLAN	Support 4K VLAN, VLAN conversion function, VLAN based on port, MAC, protocol, IP address and QinQ
MAC	8K MAC address table, support MAC address table dynamic automatic learning and static configuration
QOS	Support 8 level QOS queue, support SP, WRR queue scheduling policy
ACL	The number of ACL entries can be supported to 256
Management	Support local Console serial port and TELNET command line management; Support SSH; Support SNMP, WEB management; Support the unified management through the EMS management system independently developed by our company; Support remote device software upgrade and backup through FTP and TFTP; Support RMON performance statistics for ports
Power and power supply	No fan, low power consumption, the total power consumption of the equipment is less than 10W Industrial grade supports dc or ac power (dc parameters: default -48v: -36v ~ -72v, ac parameters: default 220V: 100V ~ 260V)
Other features	Port convergence /LACP supported, support 1:1 port protection Support interport protection based on the LACP protocol, linear protection based on the G.8031 protocol and ring network protection based on the G.8032 protocol Support port redirection and port mirror function, support port-based failover capabilities Support MSTP/RSTP protocol Support fiber breakage alarm;Support power failure warning of Dying Gasp remote device Support equipment online upgrade Support storm suppression and port speed limit, speed limit granules up to 64K Support SLA, Link performance tests such as link delay, jitter, packet loss and throughput can be implemented Support port-based, 802.1p, DSCP, TOS, MAC address, VLAN ID, Ethernet Type
Operating Temperature	Industrial grade: (-40 ° C~ 80 ° C)
Storage temperature	-40°C～85°C

Qualcomm has strong advantages in mobile chips, wireless connectivity and baseband, as well as patent reserves, especially in 3G and 4G.

Qualcomm has more than 3,900 patents in CDMA technology.

Last year, Qualcomm's Snapdragon 820 processor was excellent and was widely adopted by 115+ flagship terminals. Qualcomm is also very strong on LTE connectivity.

Application

Local Area Network
CATV System
Telecommunication Networks
Equipment Test
